About RMUX

A local client/server terminal multiplexer written from scratch in Rust. One daemon and one wire protocol behind three public surfaces: a tmux-compatible CLI, a typed Rust SDK, and a ratatui widget.

Native, no WSL

Native ConPTY with named pipes on Windows. Unix PTYs with Unix-domain sockets on Linux and macOS. The daemon never opens a network listener.

Programmable from Rust

Typed handles for Session, Window, Pane. Take structured snapshots, send keys, wait for output, subscribe to pane events. No TTY scraping.

Drop-in tmux

The full tmux 4.0.1 command surface — 90 commands, persistent sessions, your existing scripts and key bindings keep working.

Installation

Use a prebuilt RMUX binary, keep Cargo as a source-build fallback, and add the SDK to your Cargo project.

CLI

curl -fsSL https://rmux.io/install.sh | sh

irm https://rmux.io/install.ps1 | iex

cargo install rmux --locked

SDK

[dependencies]
rmux-sdk = "0.3"
tokio = { version = "1", features = ["macros", "rt-multi-thread"] }

Configuration

rmux reads config at startup. RMUX config paths win first; if none load, a filtered tmux.conf can be used as a migration fallback.

tmux.conf fallback

If no RMUX config file is loaded during the default startup search, RMUX can import a filtered tmux.conf as a migration fallback. Explicit config loading with -f does not use this fallback.

Example

# Prefix key
set -g prefix C-a
unbind C-b
bind C-a send-prefix

# Splits
bind | split-window -h
bind - split-window -v

# Mouse
set -g mouse on

Architecture

rmux runs as a local daemon. Three public surfaces — CLI, SDK, ratatui widget — share one wire protocol.

rmux runs as a local daemon that owns sessions, windows, panes, and the PTY processes inside them. Three public surfaces — a rmux CLI, a rmux-sdk Rust crate, and a ratatui-rmux widget — talk to the daemon over the same wire protocol, so anything one surface can do, the others can do too.

Runtime shape

Public surfaces

• rmux — tmux-compatible CLI, including tmux-style commands such as wait-for.
• rmux-sdk — public Rust SDK over the daemon. Typed handles, async, no exposed wire-format types.
• ratatui-rmux — ratatui integration consuming the SDK; embedding a live pane is a widget rather than a custom driver.

Automation model

• Locator queries visible terminal snapshots. It is terminal-native text matching, not a DOM or CSS selector model.
• PaneId, pane_by_id, and retained output make pane identity stable across index recompression during a daemon lifetime.
• ProcessCommandSpec::Argv and ProcessCommandSpec::Shell make launch mode explicit; command() remains legacy shell-compatible.
• Keyboard, mouse, fill, capture, screenshot, quiet-state waits, and JSONL tracing are SDK automation layers over the existing daemon protocol.
• OwnedSession cleanup policies and daemon-side leases cover app-owned workspaces, including KillOnOwnerExit.
• Capability negotiation is cached by the SDK; unsupported daemon features surface as typed RmuxError::Unsupported diagnostics.

Workspace crates

Eleven workspace crates are published on crates.io; rmux-render-core remains an internal rendering building block. Dependencies flow one way — lower crates never depend on rmux-server or rmux.

Protocol v1

Every frame on the wire follows the same envelope, defined in rmux-proto:

magic byte      0x52
wire version    varint (LEB128)
payload length  little-endian u32
payload         bincode v1 DTO

The supported wire revisions are tracked in V1_FRAME_LEDGER; breaking changes bump the varint and add a new entry rather than mutating the existing frame.

Platform model

• Linux / macOS — Unix-domain sockets for IPC, native Unix PTYs.
• Windows — named pipes for IPC, native ConPTY.
• Local-only. The daemon never opens a network listener.

From the shell

Create a detached session, send a command, synchronize with a tmux-style wait-for channel, capture the pane, then attach for interactive use.

rmux new-session -d -s demo
rmux split-window -h -t demo
rmux send-keys -t demo "printf 'test result: ok\n'; rmux wait-for -S demo-done" Enter
rmux wait-for demo-done
rmux capture-pane -p -t demo
rmux attach-session -t demo

From Rust

Start or connect to the daemon, ensure one session, write text, wait for it, then capture terminal state.

let pane = session.pane(0, 0);
pane.send_text("echo hello\n").await?;
pane.wait_for_text("hello").await?;

Terminal automation

Drive a real terminal pane with visible-text locators, keyboard actions, quiet-state waits, and visible assertions.

let pane = rmux
    .find_panes()
    .title("agent:claude")
    .one()
    .await?;

pane.get_by_text("Ready").wait_for().await?;
pane.keyboard().type_text("printf 'multiplexer ready\n'").await?;
pane.keyboard().press("Enter").await?;
pane.wait_for_load_state(TerminalLoadState::Quiet).await?;
pane.expect_visible_text().to_contain("multiplexer").await?;

PaneSet orchestration

Collect agent panes into a PaneSet, broadcast one prompt, wait across all or any pane, and inspect partial results.

let discovered = rmux
    .find_panes()
    .title_prefix("agent:")
    .running()
    .all()
    .await?;
let agents = PaneSet::new(discovered.into_iter().map(|pane| pane.pane));

agents
    .keyboard()
    .type_text("Explain rmux in one sentence.")
    .await?;
agents.keyboard().press("Enter").await?;
agents.expect_all().visible_text_contains("rmux").await;
let snapshots = agents.snapshot_all().await;

Run detached

Start a long-running process inside a detached RMUX session and return immediately.

let session = rmux
    .ensure_session(
        EnsureSession::try_named("web")?
            .create_or_reuse()
            .detached(true)
            .shell("python3 -m http.server 8000"),
    )
    .await?;

Owned session cleanup

Create a session owned by your app, choose KillOnDrop, KillOnOwnerExit, or Preserve, and make cleanup explicit.

let mut owned = rmux
    .owned_session(SessionName::new("agent-run")?)
    .replace_existing(true)
    .cleanup_policy(CleanupPolicy::KillOnOwnerExit)
    .await?;

let _signals = owned.install_default_signal_handlers()?;
let session = owned.session();
session.pane(0, 0).keyboard().type_text("cargo test\n").await?;

owned.cleanup().await?;
